Ascension Island Auxiliary Airfield Surveying and Mapping Services

DRMP provided surveying and mapping services for the full-depth replacement of the 10,000-LF runway at the Ascension Island Auxiliary Airfield.  Located in the South Atlantic Ocean between Brazil and Africa, this airfield supports strategic space launch, surveillance and operations for the United States and United Kingdom.

Surveyors performed a design-level topographic map of over 1-square mile of rugged, volcanic terrain utilizing static LiDAR and Unmanned Aerial System photogrammetry and production of new UFC-compliant, GIS airfield obstruction imaginary surfaces. Subsurface Utility Engineering included the designation and location of over 6-miles of underground water, wastewater, stormwater, primary and secondary electric and airfield lighting lines.

As the result of DRMP’s thorough surveying and mapping services, the Ascension Airfield has the proper measurement for a new and improved runway. In addition, surveying staff prepared the survey of the existing pier head and beach landing craft.



Awards

  • 2018 ACEC - National Engineering Excellence National Recognition Award in Surveying and Mapping Technology for Ascension Island Auxiliary Airfield Surveying and Mapping Services
  • 2018 ACEC - FL Engineering Excellence Grand Award in Surveying and Mapping Technology Category for Ascension Island Auxiliary Airfield Surveying and Mapping Services



Key Facts

Location:

Ascension Island

Client:

United States Air Force

Size:

10,000-LF

Highlights:
  • 10,000-LF runway
  • Compliant with United Kingdom and United States of America airfield, environmental and other engineering standards
  • Integrates aerial imagery, terrestrial static LiDAR scanning and traditional survey techniques
  • Unmanned aerial vehicle (UAV)
  • Subsurface utility engineering (SUE)
Services Provided:

Federal Services

Geographic Information Services

Subsurface Utility Engineering

Surveying & Mapping/Geospatial

Visualization Services
